1200 TON AIDA MODEL FMX-L2-10000(2) LINK MOTION 2-POINT PRESS

MODEL NUMBER: FMX-L2-10000(2)-104-142

TYPE: LINK MOTION 2-POINT PRESS

CAPACITY: 1200 TON

RATED TONNAGE POINT: 1.18"

SLIDE STROKE: 19.68"

CONTINUOUS WORKING ENERGY: 360 @ 15 SPM

SPM UNDER NO LOAD: 15-25

MICRO-INCHING: APPROX 3 SPM

DIE HEIGHT: 47.24"

SLIDE ADJUSTMENT: 1.96"

SLIDE AREA: 40.94" LR x 55.90" FB

BOLSTER AREA: 39.37" LR x 53.14" FB

BOLSTER THICKNESS: 9.84"

FLOOR LEVEL TO TOP OF BOLSTER: 15.74"

BED KNOCKOUT SPECIFICATIONS:

TYPE: MECHANICAL

CAPACITY: 100 TON AT ALL STAGE

CAPACITY OF EACH STAGE: 50 TON AT 1st, 3rd STAGE

100 TON AT 2nd STAGE

STROKE: 7.87"

DIE PIN LIFTER SPECIFICATIONS:

TYPE: PNEUMATIC

CAPACITY: 5 TON (3 STAGES)

STROKE: 7.87"

SLIDE KNOCKOUT SPECIFICATIONS:

TYPE: PNEUMATIC

CAPACITY: 5 TON

STROKE: 3.15"

TRANSFER FEEDER SPECIFICATIONS:

MODEL: TCS-40(L)

TYPE: 3-AXIS TRANSFER DEVICE (SERVO MOTOR DRIVEN)

FEED STROKE: 0 - 15.74"

CLAMPING STROKE, PER ONE SIDE: 0 - 5.90"

LIFT STROKE: 0 - 5.11"

INSIDE DISTANCE OF FEED BARS: 14.17", 15.74" AT CLAMP

HEIGHT OF FEED BAR BOTTOM FACE: 27.75" (FROM BOLSTER)

HEIGHT OF FEED BAR TOP FACE: 31.29" (FROM BOLSTER)

FEED DIRECTION: RIGHT TO LEFT
